Volvo T810

Last Updated: June 2024

Overview

The Volvo T810 is a Row-Crop tractor designed for agricultural activities such as tilling and planting. With a powerful Volvo diesel engine, it provides a robust performance for various farming tasks. The tractor has a 4x2 2WD chassis, making it well-suited for field conditions where maneuverability and traction control are essential. It is equipped with a hydrostatic power steering system which optimizes the operator's control and comfort during extended periods of work. The transmission offers 8 forward gears and 2 reverse gears allowing for a variety of speed options suited to different tasks. The tractor operates at a rated RPM of 2300, ensuring efficient power delivery across all tasks. The Volvo T810 features a 6-cylinder engine with a displacement of 334.4 cubic inches, with an output of 133 horsepower, helping to tackle heavy and time-intensive tasks. This tractor has a cab operator station type, providing shelter and comfort for the operator in various weather conditions.
Show more...

Key Specifications

Category: Row Crop

Power Output: 133

Drive Type: 2WD

Operating Weight: 11800

Fuel Type: Diesel

Volvo T810 vs. Similar Tractors

Power Output
Average
Greater than 43% of similar tractors.
Operating Weight
Average
Greater than 45% of similar tractors.

Technical Specifications

Engine

Manufacturer
Volvo
Model
-
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
6
Displacement (ci)
334.4
Bore (in)
3.87
Stroke (in)
4.724
Rated RPM
2300
Power Output (hp)
133

Transmission

Type
-
Forward Gears
8
Reverse Gears
2
Total Gears
10

Dimensions

Length (in)
167
Width (in)
82
Height (in)
102
Operating Weight (lb)
11800

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
