Volvo T814

Last Updated: June 2024

Overview

The Volvo T814 is a row-crop tractor known for its robust design and powerful performance. It's built with a 4x4 MFWD 4WD chassis, enhancing its traction and stability in various field conditions. This tractor is equipped with hydrostatic power steering, providing the operator with easier handling and maneuverability. At the heart of the T814 is the Volvo 5.5L 6-cylinder diesel engine, which provides 140 hp. This hearty power output is matched with a durable, manually operated 8-speed transmission, including 8 forward and 2 reverse gears. The tractor is designed for substantial tasks, with a significant operating weight of 14,200 lbs and a wheelbase measuring 112 inches for stability. Not to be overlooked, the Volvo T814 is outfitted with Cab, ensuring operator comfort during long working hours. Its large tires, with 14.9-inch width at the front and 18.4-inch width at the rear, are suitable for various types of agricultural operations. The T814's durable construction and powerful engine make it a reliable workhorse for modern farming.
Show more...

Key Specifications

Category: Row Crop

Power Output: 140

Transmission: Manual

Drive Type: 4WD

Operating Weight: 14200

Fuel Type: Diesel

Image Gallery

Volvo T814 vs. Similar Tractors

Power Output
Average
Greater than 48% of similar tractors.
Operating Weight
Average
Greater than 57% of similar tractors.

Technical Specifications

Engine

Manufacturer
Volvo
Model
5.5L 6-cyl diesel
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
6
Displacement (ci)
334.4
Bore (in)
3.87
Stroke (in)
4.724
Rated RPM
2300
Power Output (hp)
140

Transmission

Type
Manual
Forward Gears
8
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
172
Width (in)
90
Height (in)
102
Operating Weight (lb)
14200

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24
Front Tire Width (in)
14.9
Rear Tire Diameter (in)
38
Rear Tire Width (in)
18.4
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
