Volvo 2650

Last Updated: June 2024

Overview

The Volvo 2650 tractor, equipped with a 4x2 2WD chassis and power steering, represents a robust and capable machine suitable for various agricultural tasks. The tractor is powered by a Volvo TD60 6-cylinder turbocharged diesel engine, ensuring reliable performance across diverse operations. With a liquid-cooled system, the engine maintains stable operating temperatures. It offers ample power output of 140 hp, with a displacement of 334.4 cubic inches, and a bore and stroke of 3.87 and 4.72 inches respectively. The engine's compression ratio is 16:1, and it delivers a peak torque of 357.7 lb-ft at 1600 RPM, suitable for substantial towing and heavy-duty applications. The tractor features a two-speed power shift transmission with 14 forward and 4 reverse gears, allowing for a versatile and responsive drive. Its substantial weight of 14,550 lbs contributes to its stability and traction. The physical dimensions, with a length of 177.2 inches, width of 91.7 inches, and height of 118.1 inches, ensure the tractor's presence and workspace adequacy. Although this overview provides specific details about the engine and transmission, some operational specifications such as the hitch type and PTO speed are not available.
Show more...

Key Specifications

Power Output: 140

Transmission: Two-speed power shift

Drive Type: 2WD

Operating Weight: 14550

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Volvo
Model
TD60
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
334.4
Bore (in)
3.87
Stroke (in)
4.72
Rated RPM
2300
Power Output (hp)
140

Transmission

Type
Two-speed power shift
Forward Gears
14
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
177.2
Width (in)
91.7
Height (in)
118.1
Operating Weight (lb)
14550

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
III/II
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (inferred from "Engine - Starter volts: 12")
Brake Type
-
Hydraulic System Type
-
