Kubota SMZ85

Last Updated: June 2024

Overview

The Kubota SMZ85 is categorised as a utility tractor and comes equipped with a robust Kubota V3800-T engine. This engine is turbocharged, provides a power output of 83.8 horsepower, and operates at a rated RPM of 2600. The engine's displacement is 230 cubic inches (3.8 L), with a bore and stroke of 3.94x4.72 inches, hinting at its capability to handle demanding tasks. The chassis features a 4x4 MFWD 4WD configuration, which, along with its power steering, lends this tractor excellent maneuverability across varying terrains. The tractor's chassis supports a weight of 6437 lbs and has substantial ground clearance of 17.3 inches. The wheelbase measures 88.6 inches, helping to ensure stability. The Kubota SMZ85 is designed with comfort in mind, featuring a cab environment to protect operators from the elements. The tractor's dimensions are 149.6 inches in length, 71.9 inches in width, and it stands 100.2 inches tall. Introduced in 2006 and manufactured until 2010, this tractor falls under Kubota's Super SynerZ Series and is a solid choice for a variety of agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 83.8

Drive Type: 4WD

Operating Weight: 6437

Fuel Type: Diesel

Kubota SMZ85 vs. Similar Tractors

Power Output
Above Average
Greater than 73% of similar tractors.
Operating Weight
Average
Greater than 50% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3800-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
16-valve
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
230
Bore (in)
3.94
Stroke (in)
4.72
Rated RPM
2600
Power Output (hp)
83.8

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
149.6
Width (in)
71.9
Height (in)
100.2
Operating Weight (lb)
6437

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2010
Hitch Type
II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
