Kubota SMZ85

Last Updated: September 2024

Overview

The Kubota SMZ85 is a powerful utility tractor built from 2006 to 2010. It's part of Kubota's Super SynerZ Series and is designed for tough farm work. This tractor has a strong 4-cylinder diesel engine that makes 83.8 horsepower. The engine is turbocharged and liquid-cooled, which helps it run smoothly and efficiently.

The SMZ85 is a 4-wheel drive tractor with power steering, making it easy to handle in different conditions. It has 24 forward and 24 reverse gears, giving the driver lots of options for different tasks. The tractor has a comfortable cab for the operator and comes with a three-point hitch at the back for attaching tools. It's a big machine, measuring 149.6 inches long, 71.9 inches wide, and 100.2 inches tall. The SMZ85 weighs 6,437 pounds, which is above average for tractors of its size. It also has good ground clearance at 17.3 inches, helping it move easily over rough ground.
Show more...

Key Specifications

Category: Utility

Power Output: 84 hp (62.5 kW)

Drive Type: 4WD

Operating Weight: 6437 lb (2920 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3800-T
Cooling Type
Liquid-cooled
Valve Configuration
16-valve
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement
230 ci (3.8 L)
Bore
3.94 in (100.1 mm)
Stroke
4.72 in (119.9 mm)
Rated RPM
2600
Power Output
84 hp (62.5 kW)

Transmission

Forward Gears
24
Reverse Gears
24

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
