Kubota M5-091HDRC

Last Updated: June 2024

Overview

The Kubota M5-091HDRC features a turbocharged four-cylinder in-line engine by Kubota, with a respectable net power output of 85.5 horsepower at 2400 rpm and a peak gross power of 92.5 horsepower. It's capable of providing 76 horsepower to the PTO at 540 rpm, making it suitable for various implements. The tractor is equipped with a fully synchronized transmission offering 8 forward and 8 reverse gears paired with an electro-hydraulic shuttle for ease of direction change. The chassis and drive type are unspecified, but given the provided information on the steering, transmission, and engine, the M5-091HDRC likely offers good maneuverability and can handle a variety of tasks on the farm or job site. With a Category 2 three-point hitch and a lift capacity of nearly 4630 pounds, this tractor can work well with a range of attachments, and the operating weight of approximately 6150 pounds provides stability during operations. Hydraulic wet disc brakes provide reliable stopping power, and other operational aspects like the differential lock and multiple wet disc clutches suggest robust handling capabilities. Dimensions are given for overall length, width, and height, providing enough detail to estimate its size on a job site or when planning for storage.
Show more...

Key Specifications

Category: Utility

Power Output: 85.5

Transmission: Fully synchronized

Operating Weight: 6150.9

Lift Capacity: 4629.8

Kubota M5-091HDRC vs. Similar Tractors

Power Output
Above Average
Greater than 74% of similar tractors.
Hitch Capacity
Above Average
Greater than 74% of similar tractors.
Operating Weight
Average
Greater than 49% of similar tractors.

Technical Specifications

Engine

Manufacturer
KUBOTA
Model
M5-091HDRC
Cooling Type
-
Cylinder Orientation
Vertical
Valve Configuration
-
Fuel Type
-
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
230
Bore (in)
-
Stroke (in)
-
Rated RPM
2400
Power Output (hp)
85.5

Transmission

Type
Fully synchronized
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
156
Width (in)
79.2
Height (in)
99.6
Operating Weight (lb)
6150.9

Power Take-Off (PTO)

PTO Type
Live-independent PTO, electro-hydraulic clutch with brake
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Hydrostatic power steering
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category 2
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
4629.8
Operator Station Type
-
Starter Type
-
Brake Type
Hydraulic wet disc
Hydraulic System Type
-
