Massey Ferguson 1825E

Last Updated: September 2024

Overview

The Massey Ferguson 1825E is a compact utility tractor built for versatile farm work. It has a 4-wheel drive system and power steering, making it easy to handle in tight spaces. The tractor uses a mechanical shuttle transmission with 8 forward and 8 reverse gears, giving the operator 16 total gears to choose from.

Under the hood, the 1825E has a 3-cylinder Iseki diesel engine that's liquid-cooled. The engine is small compared to many other tractors, with 24 horsepower and a displacement of 91.4 cubic inches. It runs at a high speed of 2600 rpm, which is above average for tractors. The tractor weighs 2668 pounds, which is on the lighter side for its class. It's compact too, measuring 116.5 inches long, 52.4 inches wide, and 97.6 inches tall. The 1825E has a Category I hitch at the rear and uses an open center hydraulic system. It comes with agricultural tires and has 11 inches of ground clearance, making it suitable for various farm tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 24 hp (17.9 kW)

Transmission: Mechanical Shuttle

Drive Type: 4WD

Operating Weight: 2668 lb (1210 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Iseki
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
3
Displacement
91 ci (1.5 L)
Bore
3.43 in (87.1 mm)
Stroke
3.31 in (84.1 mm)
Rated RPM
2600
Power Output
24 hp (17.9 kW)

Transmission

Type
Mechanical Shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
16

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
