Massey Ferguson 1225

Last Updated: June 2024

Overview

The Massey Ferguson 1225 is a versatile and robust compact utility tractor that offers a convenient choice for a variety of tasks. Manufactured by Iseki for Massey Ferguson from 1999 to 2002, it boasts a reliable 1.1 L three-cylinder diesel engine model Iseki E3112, with natural aspiration and a substantial 24.3 horsepower output at 2800 RPM. It is available in both 2WD (4x2) and 4WD (MFWD 4WD), catering to different user requirements. This model comes with either gear transmission featuring 6 forward and 2 reverse gears or a hydrostatic transmission with infinite (2-range) forward and reverse gears. It is equipped with power steering, a two-post ROPS for safety, and mechanical dry shoe brakes. The tractor has a modest operating weight ranging from 1367 pounds for the 2WD gear version to 1499 pounds for the 4WD hydro version, allowing it to perform well without causing excessive soil compaction. It was designed with practicality in mind, including a Category I hitch with a lift capacity of 1213 pounds for handling various implements with ease.
Show more...

Key Specifications

Category: Utility

Power Output: 24.3

Transmission: Gear or Hydrostatic

Operating Weight: 1367 for 2WD gear, 1499 for 4WD hydro

Fuel Type: Diesel

Lift Capacity: 1213

Massey Ferguson 1225 vs. Similar Tractors

Power Output
Below Average
Greater than 16% of similar tractors.
Hitch Capacity
Below Average
Greater than 23% of similar tractors.
Operating Weight
Average
Greater than 67% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E3112
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspirated
Cylinders
3
Displacement (ci)
68.5
Bore (in)
3.07
Stroke (in)
3.07
Rated RPM
2800
Power Output (hp)
24.3

Transmission

Type
Gear or Hydrostatic
Forward Gears
6 (Gear type)
Reverse Gears
2 (Gear type)
Total Gears
-

Dimensions

Length (in)
91.1
Width (in)
41
Height (in)
75.2 (with ROPS)
Operating Weight (lb)
1367 for 2WD gear, 1499 for 4WD hydro

Power Take-Off (PTO)

PTO Type
Transmission (gear) or independent (hydro)
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
2000 (Middle PTO)
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD 4WD
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
7.5
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2002
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
1213
Operator Station Type
Two-post ROPS
Starter Type
Electric
Brake Type
Mechanical dry shoe
Hydraulic System Type
Open center
