Kubota STW37

Last Updated: June 2024

Overview

The Kubota STW37 is a compact utility tractor that is part of the STW Series. It is designed with a 4x4 MFWD 4WD chassis, providing improved traction and performance on various terrains. This model is powered by a Kubota D1803 diesel engine, with a displacement of 111.4 cubic inches, 3 cylinders, and operating at a rated RPM of 2700. The transmission is a hydrostatic type with infinite (3-range) forward and reverse gears, allowing for a smooth and variable speed adjustment. The STW37 can be fitted with different types of tires, including standard agricultural and optional lawn/turf, to suit a range of tasks. The tractor's abilities are further complemented by its power steering, and a choice of operator station types featuring either ROPS or a cab. The STW37 began its production run in 2015; however, the end year of manufacture is not available. This model achieves a balance between capability and size, making it suitable for a variety of jobs without being too cumbersome for smaller worksites.
Show more...

Key Specifications

Category: Utility

Power Output: 36.6 (EC 97/98)

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 2436 (ROPS), 2756 (Cab)

Fuel Type: Diesel

Kubota STW37 vs. Similar Tractors

Power Output
Average
Greater than 33% of similar tractors.
Operating Weight
Below Average
Greater than 19% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1803
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural Aspiration
Cylinders
3
Displacement (ci)
111.4
Bore (in)
3.4
Stroke (in)
4
Rated RPM
2700
Power Output (hp)
36.6 (EC 97/98)

Transmission

Type
Hydrostatic
Forward Gears
Infinite (3-range)
Reverse Gears
Infinite (3-range)
Total Gears
-

Dimensions

Length (in)
115.8
Width (in)
46.7
Height (in)
ROPS: 92.5, Cab: 85.2
Operating Weight (lb)
2436 (ROPS), 2756 (Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard: Agricultural, Optional: Lawn/Turf
Manufacture - End Year
-
Hitch Type
Category I Three-Point Hitch
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS or Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
