Kubota KL37Z

Last Updated: June 2024

Overview

The Kubota KL37Z is a compact utility tractor designed for various tasks around small farms or estates. It features a four-wheel-drive chassis (4x4 MFWD) that provides stability and traction. Steering operations are powered, facilitating easier maneuverability in different conditions. This Kubota model is equipped with a continuously variable transmission (CVT) with infinite gearing in both forward and reverse, promoting a flexible operating speed tailored to the job at hand. The heart of the KL37Z is a reliable Kubota V2203 diesel engine with a displacement of 134.1 cubic inches, yielding a power output of 36.5 horsepower at a rated RPM of 2600. The tractor has liquid cooling to help maintain optimal engine temperatures during prolonged operation. It features a dry disc clutch and a dual-drive CVT. Standard agricultural tires are fitted to the tractor, with dimensions of 8-18 at the front and 12.4-28 at the rear, although the exact tire dimensions are not provided. With a weight of 3990 lbs, this tractor is sturdy and built for various tasks that require substantial power. The KL37Z was manufactured from 2012 to 2015 as part of the KL Kingwel Zero Series.
Show more...

Key Specifications

Category: Utility

Power Output: 36.5

Transmission: continuously-variable transmission

Drive Type: 4WD

Operating Weight: 3990

Fuel Type: diesel

Kubota KL37Z vs. Similar Tractors

Power Output
Average
Greater than 33% of similar tractors.
Operating Weight
Average
Greater than 36% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2203
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
-
Cylinders
4-cylinder
Displacement (ci)
134.1 ci
Bore (in)
3.43
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
36.5

Transmission

Type
continuously-variable transmission
Forward Gears
infinite (assume highest number of ranges provided: 3-range)
Reverse Gears
infinite (assume highest number of ranges provided: 3-range)
Total Gears
-

Dimensions

Length (in)
133.3
Width (in)
60
Height (in)
89.8 (cab height)
Operating Weight (lb)
3990

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
Unknown (assume Front tire: 2023-08-18 00:00:00 is a data error)
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
2015
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
electric
Brake Type
-
Hydraulic System Type
-
