Fendt Farmer 309LS

Last Updated: September 2024

Overview

The Fendt Farmer 309LS is a row crop tractor designed for efficient farming. It has a 2WD drive system and power steering, making it easy to maneuver in fields. The tractor features a 21-speed forward and 6-speed reverse synchromesh transmission, giving farmers plenty of options for different tasks.

Under the hood, the Farmer 309LS boasts a MWM diesel engine with 4 cylinders and turbocharging. The engine produces 86 hp at 2350 rpm, which is average for its class. It has a liquid-cooling system to keep it running smoothly. The tractor's three-point hitch is located at the rear and can lift an impressive 14,330 lb, which is very high compared to other tractors. With agricultural tires, a comfortable cab, and an open center hydraulic system, this Fendt tractor is well-equipped for various farming jobs.
Show more...

Key Specifications

Category: Row Crop

Power Output: 86 hp (64.1 kW)

Transmission: Synchromesh

Drive Type: 2WD

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
MWM
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement
254 ci (4.2 L)
Bore
4.13 in (104.9 mm)
Stroke
4.72 in (119.9 mm)
Rated RPM
2350
Power Output
86 hp (64.1 kW)

Transmission

Type
Synchromesh
Forward Gears
21
Reverse Gears
6

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
