Zetor 9020

Last Updated: September 2024

Overview

The Zetor 9020 is a powerful 2WD tractor designed for farm work. It has a 4-cylinder diesel engine that's turbocharged and liquid-cooled. This engine puts out 93 hp at 2200 rpm, making it strong enough for many farming tasks. The tractor has a synchronized transmission with 12 forward and 12 reverse gears, giving the driver lots of options for different jobs.

This tractor is big and sturdy. It's 152 inches long, 73 inches wide, and 105 inches tall. It weighs 7090 lb, which helps it stay stable during work. The Zetor 9020 has power steering and a three-point hitch at the back for attaching tools. It also has an open center hydraulic system and agricultural tires front and back. The driver sits in a ROPS (Roll-Over Protective Structure) for safety. The tractor starts with an electric starter, making it easy to get going in the morning.
Show more...

Key Specifications

Power Output: 93 hp (69.4 kW)

Transmission: Synchronized

Drive Type: 2WD

Operating Weight: 7090 lb (3216 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Zetor
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement
254 ci (4.2 L)
Bore
4.13 in (104.9 mm)
Stroke
4.72 in (119.9 mm)
Rated RPM
2200
Power Output
93 hp (69.4 kW)

Transmission

Type
Synchronized
Forward Gears
12
Reverse Gears
12

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
