Valpadana 1555

Last Updated: June 2024

Overview

The Valpadana 1555 is a utility tractor designed for varied tasks from farming to landscaping. Powered by a 54.2 horsepower turbo diesel engine, it features a robust 4-cylinder, 121.7 cubic-inch liquid-cooled setup with an engine rated at 2800 RPM and torque peaking at 121 lb-ft at 1680 RPM. A notable aspect of this model is its shuttle/creeper 16-speed transmission boasting an equal number of forward and reverse gears, enhancing maneuverability in diverse working conditions. Its chassis underpins a 4x4 MFWD 4WD system, providing substantial traction and stability. Steering is likely power-assisted, considering the steering flow capacity. The 1555 sits on agricultural tires with a front diameter of 24 inches and a rear diameter of 28.3 inches, suitable for a variety of terrains. Measuring 132.3 inches in length, 54.5 inches in width, with a height of 84.3 inches and an operating weight of 3,594 lbs, the tractor exhibits a presence that balances capability and agility. Details such as hitch type, operator station type, PTO specifications, and brake type remain unspecified, along with the manufacturing start and end years.
Show more...

Key Specifications

Category: Utility

Power Output: 54.2

Transmission: Shuttle/Creeper

Drive Type: 4WD

Operating Weight: 3,594

Fuel Type: Diesel

Valpadana 1555 vs. Similar Tractors

Power Output
Average
Greater than 52% of similar tractors.
Operating Weight
Poor
Greater than 2% of similar tractors.

Technical Specifications

Engine

Manufacturer
Unknown
Model
4TNV84T-KLAN
Cooling Type
Liquid-cooled
Cylinder Orientation
Vertical (Assumed based on common practice for tractor engines)
Valve Configuration
OHV (Assumed based on engine model detail - common with turbo diesel engines)
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
121.7
Bore (in)
3.307
Stroke (in)
3.543
Rated RPM
2800
Power Output (hp)
54.2

Transmission

Type
Shuttle/Creeper
Forward Gears
16
Reverse Gears
16
Total Gears
32 (16 forward and 16 reverse)

Dimensions

Length (in)
132.3
Width (in)
54.5
Height (in)
84.3
Operating Weight (lb)
3,594

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power (Assumed based on steering flow spec)
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24 (calculated based on normal tire code interpretation 240/70-16)
Front Tire Width (in)
9.4 (calculated based on normal tire code interpretation 240/70-16)
Rear Tire Diameter (in)
28.3 (calculated based on normal tire code interpretation 360/70-20)
Rear Tire Width (in)
14.2 (calculated based on normal tire code interpretation 360/70-20)
Front/Rear Rim Diameter (in)
16 / 20
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Three-Point Hitch (Assumed based on Rear Type I)
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
Open Center (Assumed based on steering flow spec)
