Valpadana 3660

Last Updated: June 2024

Overview

The Valpadana 3660 is a 4-wheel drive tractor, equipped with a 58.8 horsepower diesel engine. Its chassis configuration, 4x4 MFWD 4WD, suggests it's designed for handling a variety of tasks with enhanced traction and power. This model features a transmission system that can vary - a 15-speed sync shuttle, or even high-end configurations with 30 or 40 forward and reverse gears through a power shuttle - indicating an emphasis on versatility across multiple applications. The tractor's wheelbase of 79.4 inches provides stability, and at a length of 153.5 inches and a height of 88.6 inches, it presents a considerable size for its category, supporting the 6,184-pound operating weight. With a diesel-powered, three-cylinder engine and a displacement of 201.4 cubic inches, this particular model is a robust piece of machinery for complex agricultural tasks. The specifics of its hitch system, hydraulic capabilities, and tire details remain unspecified but given its category, these would typically align with common industry standards for medium-range tractors.
Show more...

Key Specifications

Power Output: 58.8

Transmission: Sync Shuttle / Power Shuttle

Drive Type: 4WD

Operating Weight: 6184

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Unknown
Model
1103C-33
Cooling Type
Liquid (assumed based on commonality in diesel engines)
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated (assumption based on lack of detail on forced induction)
Cylinders
3
Displacement (ci)
201.4
Bore (in)
-
Stroke (in)
-
Rated RPM
-
Power Output (hp)
58.8

Transmission

Type
Sync Shuttle / Power Shuttle
Forward Gears
15 / 30 / 40
Reverse Gears
15 / 30 / 40
Total Gears
-

Dimensions

Length (in)
153.5
Width (in)
52
Height (in)
88.6
Operating Weight (lb)
6184

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
