New Holland T2410

Last Updated: June 2024

Overview

The New Holland T2410 is a compact utility tractor known for its versatility and power. Powered by a Shibaura turbocharged, four-cylinder, and liquid-cooled diesel engine, it delivers 55 horsepower and has an engine displacement of 135.2 cubic inches. Built on a robust chassis with a 4x4 MFWD 4WD system, it is equipped with a hydrostatic power steering for responsive maneuverability. Both Synchro Shuttle Shift (SSS) and Electro-Hydraulic Shuttle Shift (EHSS) transmissions are available, each boasting 12 forward and reverse gears, suitable for a variety of tasks. The tractor is designed to accommodate different types of work environments, as indicated by its multiple tire options for agricultural, lawn or turf, and industrial usage. The estimated operating weight ranges from 4260 to 5220 pounds, and it stands 71.4 inches tall with ROPS and 88.25 inches with a cab. Despite its robust build, the actual dimensions remain compact, with a length of 137.3 inches and a width of 71.6 inches, allowing for operation in smaller spaces.
Show more...

Key Specifications

Category: Utility

Power Output: 55

Operating Weight: 4260 (ROPS) - 5220

New Holland T2410 vs. Similar Tractors

Power Output
Average
Greater than 53% of similar tractors.
Operating Weight
Above Average
Greater than 87% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
-
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
turbocharged
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.307
Stroke (in)
3.937
Rated RPM
2700
Power Output (hp)
55

Transmission

Type
-
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
137.3
Width (in)
71.6
Height (in)
71.4 (ROPS), 88.25 (cab)
Operating Weight (lb)
4260 (ROPS) - 5220

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
-
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
16
Front Tire Width (in)
-
Rear Tire Diameter (in)
24
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag, Lawn/turf, Industrial
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
-
