LS Neo N53

Last Updated: June 2024

Overview

The LS Neo N53 is a 4WD tractor, featuring a Mitsubishi S4S-D diesel engine with a liquid cooling system. It comes with a sturdy chassis designed for multifunctional use, encompassing a 4x4 MFWD 4WD configuration which provides stability and traction across varied terrains. The tractor has a hydrostatic power steering system, which ensures ease of maneuverability. For transmission, it boasts a synchro shuttle system facilitating 16 forward and reverse speeds, adaptable for a range of tasks. With an engine displacement of 203.3 cubic inches, the LS Neo N53 delivers a power output of 57 horsepower at a rated RPM of 2500. This workhorse has a significant operating weight of 5,556 pounds and dimensions that include a wheelbase of 81.7 inches, a length of 142 inches, and a height of 96.7 inches. Additional cleaning features for the engine include a precleaner and oil bath, which help in maintaining engine efficiency and longevity.
Show more...

Key Specifications

Power Output: 57

Transmission: Synchro shuttle

Drive Type: 4WD

Operating Weight: 5556

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4S-D
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
203.3
Bore (in)
3.701
Stroke (in)
4.724
Rated RPM
2500
Power Output (hp)
57

Transmission

Type
Synchro shuttle
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
142
Width (in)
55.4
Height (in)
96.7
Operating Weight (lb)
5556

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Rear Type I/II
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
