CaseIH Puma 115

Last Updated: September 2024

Overview

The CaseIH Puma 115 is a powerful utility tractor built for tough farm work. It has a strong 6-cylinder diesel engine that makes 115 horsepower. This engine is very big for its class, with 411 cubic inches of displacement. The tractor is also quite heavy, weighing 13,230 pounds, which helps it handle big jobs.

This Puma model has four-wheel drive and hydrostatic power steering, making it easy to control in different conditions. It has an 18-speed transmission with 6 reverse gears, giving the driver lots of options. The hydraulic system is advanced, using a closed center design that saves fuel. For safety, it has wet disc brakes that work well even in muddy conditions. The tractor also has a 12-volt electrical system and an air-cooled engine for better performance.
Show more...

Key Specifications

Category: Utility

Power Output: 115 hp (85.8 kW)

Transmission: 18-speed partial power shift

Drive Type: 4WD

Operating Weight: 13230 lb (6001 kg)

Fuel Type: Diesel

CaseIH Puma 115 vs. Similar Tractors

Power Output

The Power Output for the CaseIH Puma 115 is Above Average. It is greater than 88% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the CaseIH Puma 115 is Excellent. It is greater than 92% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the CaseIH Puma 115 is Excellent. It is greater than 91% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the CaseIH Puma 115 is Below Average. It is greater than 28% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
CNH
Cooling Type
Liquid
Cylinder Orientation
Inline
Valve Configuration
24-valve
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement
411 ci (6.7 L)
Bore
4.09 in (104.0 mm)
Stroke
5.20 in (132.0 mm)
Rated RPM
2200
Power Output
115 hp (85.8 kW)

Transmission

Type
18-speed partial power shift
Forward Gears
18
Reverse Gears
6

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Brake Type
Hydraulic wet disc
