Agco LT95A

Last Updated: July 2024

Overview

The Agco LT95A is a robust tractor designed for various agricultural tasks. It features a turbocharged and intercooled engine with a displacement of 268 cubic inches, producing a maximum power of 111.60 HP at standard PTO speed. The tractor is equipped with a 16-speed powershift transmission, offering 16 forward and 16 reverse gears. With an operating weight of 11,070 lbs, it's built for heavy-duty work. The hydraulic system boasts a standard pump flow capacity of 24.1 GPM, and the hitch can exert a maximum force of 7,817 lbs. The LT95A also features impressive fuel efficiency, with 16.52 Hp.hr/gal at standard PTO speed. Its noise levels are relatively low, measuring 71.4 dB(A) at no load in 7th gear. This tractor combines power, efficiency, and versatility for modern farming needs.

Key Specifications

Power Output: 111.60 (PTO)

Transmission: Powershift

Operating Weight: 11070

Lift Capacity: 7817

Image Gallery

Agco LT95A Tractor

Technical Specifications

Engine

Manufacturer: -
Model: -
Cooling Type: -
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: -
Induction Type: Turbocharged/Intercooled
Cylinders: -
Displacement (ci): 268
Bore (in): -
Stroke (in): -
Rated RPM: 2200
Power Output (hp): 111.60 (PTO)

Transmission

Type: Powershift
Forward Gears: 16
Reverse Gears: 16
Total Gears: -

Dimensions

Length (in): 172.8
Width (in): -
Height (in): Not specified in test results
Operating Weight (lb): 11070

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: Category II
Hitch Category: 2
Hitch Position: -
Hitch Capacity (lb): 7817
Operator Station Type: Cab
Starter Type: -
Brake Type: -
Hydraulic System Type: -

Test Results

Nebraska Tractor Test Laboratory - Test Date: June 11 - 24, 2008

Maximum Power and Fuel Consumption

Maximum Power: 112.32 HP (83.75 kW) at 1950 rpm
Fuel Consumption at Maximum Power: 6.66 Gal/hr (25.21 l/h) with a fuel efficiency of 0.415 lb/hp.hr (0.253 kg/kW.h)
Fuel Efficiency at Standard PTO Speed (1000 rpm): 16.52 Hp.hr/gal (3.25 kW.h/l)

Drawbar Performance

Power at Rated Engine Speed: Not specified in the provided data
Maximum Torque: 369 lb.-ft. (500 Nm) at 1450 rpm
Torque Rise: 56.1% with a power increase at 1950 rpm of 13.2%

Hydraulic Performance

Maximum Force Exerted: 9189 lbs (40.9 kN) with 75 mm lift cylinders
Pump Delivery Rate: 29.8 GPM (112.7 l/min) at minimum pressure and rated engine speed
Hydraulic Power: 38.2 HP (28.5 kW) at delivery pressure of 2708 psi (187 bar)

Sound Levels

Sound Level at No Load in 7th Gear: 71.4 dB(A)
Bystander Sound Level in 16th Gear: 84.3 dB(A)

Overall Efficiency

Fuel Efficiency at Rated Speed: 14.89 Hp.hr/gal (2.93 kW.h/l)
Fuel Consumption: 6.66 Gal/hr (25.22 l/h) at 2200 rpm

Nebraska Tractor Test Lab.(2008).Nebraska Tractor Test 1932: AGCO LT95A. Lincoln, NE: Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2282
