CaseIH Optum 270

Last Updated: September 2024

Overview

The CaseIH Optum 270 is a powerful row crop tractor built for serious farming. It has a strong 6-cylinder diesel engine made by FPT that puts out 271 horsepower, which is very high compared to other tractors. The engine is turbocharged and has special cooling to help it run well. This tractor uses a CVT transmission, which means it has infinite gears for smooth driving in the field or on the road.

The Optum 270 is a big tractor, measuring 208.2 inches long and weighing 23,149 pounds. It has four-wheel drive and power steering to help it move easily in tough conditions. The tractor has a three-point hitch in the back for attaching tools. Inside, there's a comfortable cab for the driver. This tractor is made to be eco-friendly, meeting Tier IV emissions standards with a special system to clean its exhaust. It also has big agricultural tires and a strong hydraulic system for running equipment.
Show more...

Key Specifications

Category: Row Crop

Power Output: 271 hp (202.1 kW)

Transmission: CVT

Drive Type: 4WD

Operating Weight: 23149 lb (10500 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
FPT
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Electronic variable geometry turbocharged with air-to-air aftercooling
Cylinders
6
Displacement
411 ci (6.7 L)
Bore
4.09 in (104.0 mm)
Stroke
5.20 in (132.0 mm)
Rated RPM
2100
Power Output
271 hp (202.1 kW)

Transmission

Type
CVT
Forward Gears
Infinite (4 range)
Reverse Gears
Infinite (2 range)

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
