Shibaura SD2240

Last Updated: June 2024

Overview

The Shibaura SD2240 is a compact utility tractor renowned for its balance between size and power. It features a 4x4 MFWD 4WD chassis providing enhanced traction and capability over diverse terrains. Equipped with a Shibaura LET852 diesel engine, this tractor offers a reliable 22 horsepower with a displacement of 62.3 cubic inches. It utilises a 12-speed gearbox, though conflicting data suggests a 24 forward and 8 reverse gear configuration which may indicate a misprint or separate model variation. Water serves as the cooling agent for this engine, ensuring consistent performance and engine longevity. The tractor's physical dimensions make it suitable for various tasks with a length of 101 inches, a width of 53 inches, and a height of 56 inches. The operating weight of 2554 pounds points towards a substantial build quality and capability for a range of utility tasks. However, detailed specifications such as tire sizes and types, steering and brake systems, available PTO speeds, as well as hitch capabilities, are lacking which precludes a complete assessment of its potential applications.
Show more...

Key Specifications

Category: Utility

Power Output: 22

Drive Type: MFWD 4WD

Operating Weight: 2554

Fuel Type: Diesel

Shibaura SD2240 vs. Similar Tractors

Power Output
Below Average
Greater than 13% of similar tractors.
Operating Weight
Below Average
Greater than 20% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
LET852
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
2
Displacement (ci)
62.3
Bore (in)
-
Stroke (in)
-
Rated RPM
-
Power Output (hp)
22

Transmission

Type
-
Forward Gears
24
Reverse Gears
8
Total Gears
32

Dimensions

Length (in)
101
Width (in)
53
Height (in)
56
Operating Weight (lb)
2554

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
