Deutz-Fahr M650

Last Updated: June 2024

Overview

The Deutz-Fahr M650 is a robust powerhouse, engineered for reliability and durability. Its 4WD chassis offers excellent stability and maneuverability, even on challenging terrains. It features power steering for easy operation and a 24-speed partial power shift transmission for smooth gear transitions. Under the hood, the M650 is equipped with a 6-cylinder Deutz engine, turbocharged and intercooled for maximum performance. It boasts a power output of 181 horsepower, capable of tackling demanding tasks with ease. Its cooling is efficient, thanks to the liquid-cooled system. The operator cab offers a comfortable workspace while the load sensing hydraulic system ensures optimal performance of the tractor’s hydraulic accessories.
Show more...

Key Specifications

Power Output: 181

Transmission: Partial power shift

Drive Type: 4WD

Operating Weight: 14880

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Deutz
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
6
Displacement (ci)
369.6
Bore (in)
3.98
Stroke (in)
4.96
Rated RPM
2100
Power Output (hp)
181

Transmission

Type
Partial power shift
Forward Gears
-
Reverse Gears
-
Total Gears
24

Dimensions

Length (in)
189.4
Width (in)
-
Height (in)
122.8
Operating Weight (lb)
14880

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power steering
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2009
Hitch Type
-
Hitch Category
Category III/II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Load sensing
