Agrinar T-180

Last Updated: June 2024

Overview

The Agrinar T-180 is a 4-wheel drive tractor, emphasizing robust power and efficiency provided by its Perkins T6 354-4 turbocharged diesel engine. With its sizable 6-cylinder engine, it can produce up to 182.5 horsepower and a torque of 435.2 lb-ft at a rated 2400 RPM, making it well-suited for heavy-duty agricultural tasks. The tractor has a liquid-cooled engine to maintain optimal operating temperatures and a large oil capacity of 20.1 quarts. Its 12-speed transmission with 12 forward and 5 reverse gears allows for a wide range of speeds well-placed for various farming needs. The tractor is fitted with large agricultural tires, 16.9 inches wide at the front and 24.5 inches wide at the rear, allowing for better traction and stability in various field conditions. Detailed specification about dimensions, operating weight, hitch capabilities, PTO speeds, and more would help paint a complete picture of the tractor, but these specifics were not provided.
Show more...

Key Specifications

Power Output: 182.5

Drive Type: 4WD

Fuel Type: Turbo Diesel

Technical Specifications

Engine

Manufacturer
Perkins
Model
T6 354-4
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbo Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
353.9
Bore (in)
3.875
Stroke (in)
5
Rated RPM
2400
Power Output (hp)
182.5

Transmission

Type
-
Forward Gears
12
Reverse Gears
5
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
23.3
Front Tire Diameter (in)
28
Front Tire Width (in)
16.9
Rear Tire Diameter (in)
32
Rear Tire Width (in)
24.5
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
