Zetor Forterra 130 HD

Last Updated: June 2024

Overview

The Zetor Forterra 130 HD is designed with farming tasks in mind, acting as a utility tractor fit for a range of agricultural needs. With a 127 horsepower, turbocharged intercooled diesel engine and a liquid-cooling system, the Forterra 130 HD boasts ample power, efficiency, and long hours of operation without overheating. The tractor operates on a four-wheel drive (4WD) chassis, supporting Multi-Function Drive (MFWD) for better traction and performance on challenging terrains. The Forterra 130 HD also includes a power steering system for easier handling and maneuverability. The engine's capacity is 253.6 cubic inches with a bore and stroke of 4.13 inches and 4.72 inches, respectively. The vehicle dimensions stand at a length of 187.8 inches and a height of 111.8 inches, with an operating weight of 10,626 lbs, which points to a solid and stable machine for heavy-duty work. This model offers an electric starter system for reliable ignition and features agricultural-type tires suitable for farm environments. Details such as PTO speeds and hydraulic system type were not specified, and some of the additional detailed specifications such as the manufacture start/end years, hitch details, and brake types are unavailable.
Show more...

Key Specifications

Category: Utility

Power Output: 127

Drive Type: 4WD MFWD

Operating Weight: 10626

Fuel Type: Diesel

Zetor Forterra 130 HD vs. Similar Tractors

Power Output
Above Average
Greater than 88% of similar tractors.
Operating Weight
Average
Greater than 64% of similar tractors.

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z 1506
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged Intercooled
Cylinders
4
Displacement (ci)
253.6
Bore (in)
4.13
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
127

Transmission

Type
-
Forward Gears
30
Reverse Gears
30
Total Gears
-

Dimensions

Length (in)
187.8
Width (in)
-
Height (in)
111.8
Operating Weight (lb)
10626

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4WD
Drive Type
4WD MFWD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agriculture
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
