Zetor Forterra 130

Last Updated: June 2024

Overview

The Zetor Forterra 130 is a robust utility tractor designed to provide reliable performance for various agricultural tasks. It features a 4-cylinder, 16-valve, turbocharged intercooled diesel engine that produces 126 horsepower and 406.4 lb-ft of torque, ensuring robust operating capabilities when working with heavy loads or challenging conditions. With a 24 forward and 18 reverse gear transmission, operators have a wide range of speed options for precision work. Power steering aids in maneuverability, while the cab height of 111.4 inches and a weight of 10274 lbs reflect a tractor built for substantial tasks without being unwieldy. The large wheelbase of 98 inches provides stability, and the liquid cooling system maintains optimal engine temperature. Its chassis, described as 4x4 MFWD 4WD, indicates a mechanically front-wheel-drive system with a four-wheel drive capability, which facilitates traction in various terrains. The Zetor Forterra 130 is equipped with standard agricultural tires sized 420/70R24 at the front and 520/70R38 at the rear, contributing to its reliable performance in diverse farmland environments. The legacy and engineering of Zetor tractors culminate in the Forterra 130's design, delivering a blend of power and efficiency essential for modern farming operations.
Show more...

Key Specifications

Power Output: 126

Drive Type: 4WD

Operating Weight: 10274

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z 1506
Cooling Type
Liquid
Cylinder Orientation
-
Valve Configuration
16-valve
Fuel Type
Diesel
Induction Type
Turbocharged Intercooled
Cylinders
4
Displacement (ci)
253.6
Bore (in)
4.13
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
126

Transmission

Type
-
Forward Gears
24
Reverse Gears
18
Total Gears
-

Dimensions

Length (in)
183.9
Width (in)
-
Height (in)
111.4
Operating Weight (lb)
10274

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
