Zetor Forterra 120 HSX

Last Updated: June 2024

Overview

The Zetor Forterra 120 HSX is a durable and versatile tractor designed for a variety of agricultural tasks. With its 4WD (four-wheel drive) chassis and power steering, it offers good maneuverability and traction across different types of terrain. The Z 1406 engine provides a liquid-cooled, turbocharged diesel platform ensuring efficient performance under varying load conditions. The tractor is equipped with a robust 30-speed fully synchronized gearbox allowing for a perfect match of speed to task. The 117 horsepower engine is well-suited for heavy-duty work, and together with a weight of 10494 lbs and a height of 111.4 inches, it performs reliably for various farming needs. The specifications like wheelbase, engine torque, and starting system are well documented, ensuring a well-rounded profile of what to expect from the Forterra 120 HSX.
Show more...

Key Specifications

Power Output: 117

Drive Type: 4WD

Operating Weight: 10494

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z 1406
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged with intercooler
Cylinders
4
Displacement (ci)
253.6
Bore (in)
4.13
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
117

Transmission

Type
-
Forward Gears
30
Reverse Gears
30
Total Gears
60

Dimensions

Length (in)
187.8
Width (in)
-
Height (in)
111.4
Operating Weight (lb)
10494

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
