Zetor 7540

Last Updated: September 2024

Overview

The Zetor 7540 is a powerful 4-wheel drive tractor built for tough farm work. It has a strong diesel engine made by Zetor, with 4 cylinders and 71 horsepower. This engine is cooled by liquid and doesn't need extra air pushed into it to work well. The tractor can go forward in 18 different speeds and backward in 6 speeds, giving the driver lots of choices for different jobs.

This tractor is big and sturdy, measuring 153.5 inches long, 75.9 inches wide, and 109.2 inches tall. It weighs 8,095 pounds, which helps it stay stable during heavy work. The Zetor 7540 has special farm tires on both the front and back, with big 38-inch tires on the rear for good traction. It also has a comfortable cab for the driver and a hydraulic system to help lift and move heavy tools. With its strong build and useful features, the Zetor 7540 is a great helper for many types of farm work.
Show more...

Key Specifications

Power Output: 71 hp (52.9 kW)

Transmission: Synchromesh

Drive Type: 4WD

Operating Weight: 8095 lb (3672 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z 7801
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement
254 ci (4.2 L)
Bore
4.13 in (105.0 mm)
Stroke
4.72 in (120.0 mm)
Rated RPM
2200
Power Output
71 hp (52.9 kW)

Transmission

Type
Synchromesh
Forward Gears
18
Reverse Gears
6

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
