Zetor 7320

Last Updated: June 2024

Overview

The Zetor 7320 is a utility tractor designed for various agricultural tasks. It features a turbocharged, liquid-cooled, four-cylinder Zetor Z7301 diesel engine with a displacement of 239 ci (3.9 L), providing 78 hp (58.2 kW) of power at 2200 RPM. This tractor's chassis is a 4x2 2WD setup, with power steering for easier maneuverability. It is equipped with a synchro transmission, giving the driver 10 forward and 2 reverse speeds. The design of the tractor facilitates ease of use in a variety of conditions with a wheelbase of 88 inches and an operating weight of 6800 lbs (3084 kg). The tractor rides on Ag front tires sized 10.00-16 and rear tires sized 16.9-34, capable of traversing various terrains. The tractor also features hydraulic cerametallic disc clutch, mechanical shuttle, and open center hydraulic system-type, enhancing its operational capabilities.
Show more...

Key Specifications

Category: Utility

Power Output: 78

Transmission: Synchro

Drive Type: 2WD

Operating Weight: 6800

Fuel Type: Diesel

Zetor 7320 vs. Similar Tractors

Power Output
Average
Greater than 69% of similar tractors.
Operating Weight
Average
Greater than 51% of similar tractors.

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z7301
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
239
Bore (in)
4.02
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
78

Transmission

Type
Synchro
Forward Gears
10
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
144
Width (in)
73
Height (in)
104 (cab height)
Operating Weight (lb)
6800

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
II/I
Hitch Category
3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
