Zetor 7040

Last Updated: June 2024

Overview

The Zetor 7040 is a utility tractor equipped with a 4-wheel drive system that ensures better traction and performance, especially in challenging terrains. It features a 4-cylinder turbocharged diesel engine with a displacement of 254 cubic inches, producing up to 70 horsepower at a rated RPM of 2200. The tractor benefits from a power steering system which enhances maneuverability. It has a synchronized transmission system with 12 forward and reverse gears, offering versatility for a variety of tasks. The tractor's dimensions show a length of 152 inches, height of 103 inches, and operating weight of approximately 7690 pounds for the ROPS version and 8190 pounds for the Cab version, which ensures stability and solid handling during operation. Its notable wheelbase of 89 inches provides a balance between stability and agility. The Zetor 7040 boasts a liquid-cooled engine, which is essential for maintaining optimal temperatures and performance during prolonged periods of work.
Show more...

Key Specifications

Category: Utility

Power Output: 70

Transmission: Synchronized

Drive Type: 4WD

Operating Weight: 7690 (ROPS), 8190 (Cab)

Fuel Type: Diesel

Zetor 7040 vs. Similar Tractors

Power Output
Average
Greater than 64% of similar tractors.
Operating Weight
Average
Greater than 55% of similar tractors.

Technical Specifications

Engine

Manufacturer
Zetor
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
254
Bore (in)
4.13
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
70

Transmission

Type
Synchronized
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
152
Width (in)
73
Height (in)
103
Operating Weight (lb)
7690 (ROPS), 8190 (Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24
Front Tire Width (in)
11.2
Rear Tire Diameter (in)
30
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
II/I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS, Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
