Zetor 6341

Last Updated: June 2024

Overview

The Zetor 6341 is a utility tractor known for its robustness and versatility, primarily used in farm operations. Its chassis supports a 4x4 MFWD 4WD wheel configuration, indicative of a tractor capable of handling a variety of terrains with its four-wheel drive system. Power steering facilitates handling, while the 10-speed synchro mesh with mech shuttle transmission is designed for reliable and flexible operation. This tractor is powered by a 66 horsepower, liquid-cooled, diesel engine, providing sufficient power for diverse agricultural tasks. The engine runs at a rated RPM of 2200 and sports a displacement of 239 cubic inches. The wheelbase measures at 73 inches, supporting a stable stance for operations, and the tractor’s weight stands at 7800 pounds, hinting at its ability to handle substantial loads. Tires are sized at 12.4-24 for the front and 16.9-34 for the rear, designed for agricultural use. The Zetor 6341 also features power steering and an open-center hydraulic system, enhancing its utility and ease of use.
Show more...

Key Specifications

Category: Utility

Power Output: 66

Transmission: Synchro mesh with mech shuttle

Drive Type: 4WD

Operating Weight: 7800

Fuel Type: Diesel

Zetor 6341 vs. Similar Tractors

Power Output
Average
Greater than 62% of similar tractors.
Operating Weight
Average
Greater than 56% of similar tractors.

Technical Specifications

Engine

Manufacturer
Zetor
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
239
Bore (in)
4.016
Stroke (in)
4.724
Rated RPM
2200
Power Output (hp)
66

Transmission

Type
Synchro mesh with mech shuttle
Forward Gears
10
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
144
Width (in)
73
Height (in)
104 (with cab)
Operating Weight (lb)
7800

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24
Front Tire Width (in)
12.4
Rear Tire Diameter (in)
34
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Three-Point Hitch (contains both Category II and Category I)
Hitch Category
II/I
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (indicated by starter volts)
Brake Type
-
Hydraulic System Type
Open Center
