Zetor 11211

Last Updated: June 2024

Overview

The Zetor 11211 is a row-crop tractor well suited for a variety of agricultural tasks. Powered by a 105 hp, 6.8 L six-cylinder diesel engine with direct injection, this tractor offers robust performance and durability. The engine operates at a rated RPM of 2200 and is liquid-cooled, ensuring efficient heat management during long working hours. The chassis is built around a 4x2 two-wheel-drive system and fitted with power steering which allows for easy maneuvering. The transmission is a synchromesh type with 16 forward and 8 reverse gears, coupled with a 380mm hydraulic dry disc clutch, providing versatility and control in various field conditions. This model boasts a hefty operating weight of 10075 lbs, allowing for stability and traction when tackling tasks that require substantial effort. The tractor's dimensions are considerable, with a length of 173.2 inches, width of 76.8 inches, and a height - considering the cab option - of 106.7 inches. The standard agricultural tires are sized 11.5x15 in the front and 16.9x38 in the rear, supporting the tractor's weight and providing adequate ground clearance. The Zetor 11211 is equipped with an open center hydraulic system and a Category 2 rear hitch, though its lift capacity remains unspecified. The tractor's design is both practical and straightforward, intended for ease of use and maintenance.
Show more...

Key Specifications

Category: Row Crop

Power Output: 105

Transmission: Synchromesh

Drive Type: 2WD

Operating Weight: 10075

Fuel Type: Diesel

Zetor 11211 vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.
Operating Weight
Average
Greater than 35% of similar tractors.

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z 8701.13
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
6
Displacement (ci)
417.5
Bore (in)
4.33
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
105

Transmission

Type
Synchromesh
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
173.2
Width (in)
76.8
Height (in)
106.7 (assuming cab height is the overall height)
Operating Weight (lb)
10075

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
15
Front Tire Width (in)
11.5
Rear Tire Diameter (in)
38
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category 2
Hitch Category
Category 2 (not 3)
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
