Zetor 10741

Last Updated: July 2024

Overview

The Zetor 10741 is a 4-wheel drive utility tractor, designed to offer both versatility and power for various agricultural tasks. Its turbocharged diesel engine has a displacement of 253.6 cubic inches, generating 101 horsepower at 2200 RPM. The tractor operates with a three-speed power shift transmission, offering 24 forward and 18 reverse gears. Equipped with power steering for ease of maneuverability and a comfortable cab for the operator, the 10741 is designed for long working hours with reduced operator fatigue. This model has a 4x4 MFWD 4WD chassis, indicating that it has a mechanical front-wheel-drive system, providing increased traction in various field conditions. The tractor has an operating weight of 9500 pounds and features a three-point hitch with Category 2/1, suited for a wide range of attachments. The utility-focused build allows for considerable ground clearances, such as 19 inches, addressing rough terrain requirements.

Key Specifications

Category: Utility

Power Output: 101

Transmission: Three-speed power shift

Drive Type: 4WD

Operating Weight: 9500

Fuel Type: Diesel

Image Gallery

Zetor 10741 Tractor

Zetor 10741 vs. Similar Tractors

Power Output

Above Average

Greater than 82% of similar tractors.

Operating Weight

Average

Greater than 62% of similar tractors.

Technical Specifications

Engine

Manufacturer: Zetor
Model: -
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 4
Displacement (ci): 253.6
Bore (in): 4.134
Stroke (in): 4.724
Rated RPM: 2200
Power Output (hp): 101

Transmission

Type: Three-speed power shift
Forward Gears: 24
Reverse Gears: 18
Total Gears: -

Dimensions

Length (in): 170
Width (in): 87
Height (in): 109 (cab height)
Operating Weight (lb): 9500

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag (Agricultural)
Manufacture - End Year: -
Hitch Type: Three-Point Hitch
Hitch Category: Category 2/1
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: Cab
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Open Center

Test Results

Nebraska Tractor Test Laboratory - Test Date: March to June 1998

Maximum Power and Fuel Consumption

Rated Engine Speed (PTO speed-1128 rpm): 90.3 HP (67.3 kW) at 2200 rpm
Fuel Consumption at Maximum Power: 5.95 Gal/hr (22.54 l/h) with a fuel efficiency of 0.458 lb/hp.hr (0.279 kg/kW.h) and 15.16 Hp.hr/gal (2.99 kW.h/l)
Maximum Power (2 hours): 91.2 HP (68.0 kW) at 2100 rpm

Drawbar Performance

Maximum Power—15th (1 Hi H) Gear: 72.7 HP (54.2 kW) with a drawbar pull of 4340 lbs (19.3 kN) and a speed of 6.28 mph (10.11 km/h) with 4.4% slip
Fuel Consumption in 15th Gear: 0.531 lb/hp.hr (0.323 kg/kW.h) with 13.20 Hp.hr/gal (2.60 kW.h/l)

Torque and Engine Performance

Maximum Torque: 286 lb.-ft. (388 Nm) at 1500 rpm
Torque Rise: 32.9%

Hydraulic Performance

Maximum Force Exerted at 24" frame: 8835 lbs (39.3 kN)
Pump Delivery Rate at Minimum Pressure: 17.4 GPM (66.0 l/min)
Hydraulic Power: 21.8 HP (16.2 kW) at delivery pressure of 2350 psi (162 bar)

Nebraska Tractor Test Lab.(1998). Nebraska Summary: S445 Zetor 10741. University of Nebraska-Lincoln: Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2841
