Yanmar YM273

Last Updated: June 2024

Overview

The Yanmar YM273 is a compact utility tractor that was designed for a variety of tasks around the farm or homestead. It features a Yanmar 2W90S 2-cylinder liquid-cooled diesel engine with a displacement of 69.9 cubic inches and an output of 24 horsepower at 2,700 RPM. Equipped with a simple 4x2 2WD chassis, the tractor offers basic maneuverability suitable for flat terrain or gentle slopes. Its gear transmission includes 6 forward gears and 2 reverse gears, catering to varying working conditions. The tractor starts with an electric starter, which is a convenient feature for operators. While the specific dimensions, weight, and other performance metrics are not provided, this model is assumed to offer the functional versatility typical of compact utility tractors of this era. Key specifications like hitch type and capacity, hydraulic system, and PTO speeds are unspecified but could be investigated further based on the model year or optional equipment available for the YM273.
Show more...

Key Specifications

Category: Utility

Power Output: 24

Transmission: Gear

Drive Type: 2WD

Fuel Type: Diesel

Yanmar YM273 vs. Similar Tractors

Power Output
Below Average
Greater than 16% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
2W90S
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
2
Displacement (ci)
69.9
Bore (in)
-
Stroke (in)
-
Rated RPM
2700
Power Output (hp)
24

Transmission

Type
Gear
Forward Gears
6
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
