Yanmar YM2210

Last Updated: September 2024

Overview

The Yanmar YM2210 is a small utility tractor that was made from 1977 to 1981. It has a 2WD chassis and is powered by a Yanmar 2T90 diesel engine. This engine has two cylinders and is liquid-cooled. It produces 21.7 hp, which is below average for tractors. The engine size is also smaller than most, but it runs at a very high speed of 2600 rpm.

This tractor has a partial power shift transmission with 15 forward gears and 5 reverse gears. It's quite light, weighing only 2094 lb, which is below average for tractors. The YM2210 is compact, measuring 109.4 inches long, 45.7 inches wide, and 72.4 inches tall. It has an open operator station and uses an electric starter. The tractor is equipped with a Category I hitch and a 540 rpm PTO. It has agricultural tires on both front and rear, making it suitable for farm work.
Show more...

Key Specifications

Category: Utility

Power Output: 22 hp (16.2 kW)

Transmission: Partial Power Shift

Drive Type: 2WD

Operating Weight: 2094 lb (950 kg)

Fuel Type: Diesel

Yanmar YM2210 vs. Similar Tractors

Power Output

The Power Output for the Yanmar YM2210 is Below Average. It is greater than 12% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 3.6K+ tractors in our database)

Operating Weight

The Operating Weight for the Yanmar YM2210 is Below Average. It is greater than 14% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 3.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Yanmar YM2210 is Below Average. It is greater than 11% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Yanmar YM2210 is Above Average. It is greater than 77% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Yanmar
Model
2T90
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Fuel Type
Diesel
Induction Type
Natural Aspiration
Cylinders
2
Displacement
70 ci (1.1 L)
Bore
3.54 in (89.9 mm)
Stroke
3.54 in (89.9 mm)
Rated RPM
2600
Power Output
22 hp (16.2 kW)

Transmission

Type
Partial Power Shift
Forward Gears
15
Reverse Gears
5
Total Gears
15 forward and 5 reverse

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
