Yanmar YM147

Last Updated: June 2024

Overview

The Yanmar YM147 is a sub-compact utility tractor, recognized for its dependability and versatility. With a liquid-cooled 14 hp Yanmar diesel engine, it presents a robust solution for a variety of tasks. Boasting a 4x2 2WD chassis and a two-speed power shift transmission with 6 forward and 3 reverse gears, the YM147 is both functional and straightforward to use. Its 2-cylinder engine revs up to 2600 RPM to deliver reliable performance. The open operator station accommodates straightforward access and operation, while the rear Category I hitch provides compatibility with a range of attachments. The tractor’s size and weight make it suitable for smaller properties or light-duty tasks. The YM147 can be fitted with different tire options depending on the intended use, ranging from agricultural to lawn or turf applications.

Key Specifications

Category: Utility, Sub-Compact

Power Output: 14

Transmission: Two-speed power shift

Drive Type: 2WD

Operating Weight: 1111 (2WD), 1204 (4WD)

Fuel Type: Diesel

Image Gallery

Yanmar YM147 Tractor

Yanmar YM147 vs. Similar Tractors

Power Output

Poor

Greater than 2% of similar tractors.

Operating Weight

Average

Greater than 65% of similar tractors.

Technical Specifications

Engine

Manufacturer: Yanmar
Model: 2T75UA
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally Aspirated
Cylinders: 2
Displacement (ci): 38.8
Bore (in): 2.95
Stroke (in): 2.83
Rated RPM: 2600
Power Output (hp): 14

Transmission

Type: Two-speed power shift
Forward Gears: 6
Reverse Gears: 3
Total Gears: -

Dimensions

Length (in): 97.5
Width (in): 38.4 (2WD), 39 (4WD)
Height (in): 48.2 (2WD), 48.6 (4WD)
Operating Weight (lb): 1111 (2WD), 1204 (4WD)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural/Industrial/Lawn/Turf (Multiple options available)
Manufacture - End Year: -
Hitch Type: Category I
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: Open
Starter Type: 12 volts
Brake Type: -
Hydraulic System Type: Open Center
