Yanmar Lx450

Last Updated: June 2024

Overview

The Yanmar Lx450 is a compact utility tractor designed for a variety of tasks on the farm, in the field, or at job sites. It features a 4-wheel drive with a 4x4 MFWD chassis, providing good traction and handling capabilities across different terrains. Equipped with a Yanmar diesel engine, it has a displacement of 133.6 cubic inches, with a power output of 45 horsepower at 2700 RPM. The engine's direct injection and liquid-cooling system ensure efficient operation and temperature management. Steering is made more manageable by its hydraulic power-steering system, and the tractor's movements are controlled with a 12-speed power shuttle transmission, allowing for a diverse range of speed settings for both forward and reverse operations. The tractor maintains an operating weight of 3,585 lbs, with a length of 124 inches and a width of 69.5 inches, providing stability and ample space for maneuverability. The Lx450 approaches various tasks with a Category 1 hitch and an open center hydraulic system, although specific details about PTO speeds and hitch capacity remain unspecified.
Show more...

Key Specifications

Category: Utility

Power Output: 45

Transmission: Power shuttle

Drive Type: 4WD

Operating Weight: 3585

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Yanmar
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement (ci)
133.6
Bore (in)
3.465
Stroke (in)
3.543
Rated RPM
2700
Power Output (hp)
45

Transmission

Type
Power shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
124
Width (in)
69.5
Height (in)
-
Operating Weight (lb)
3585

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydraulic power
Coolant Capacity (qts)
5.1
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category 1
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
