Yanmar FX195

Last Updated: June 2024

Overview

The Yanmar FX195 is a compact utility tractor that is designed for various agricultural tasks in smaller farm settings. Equipped with a 2WD chassis setup, this tractor offers a Yanmar 3TNB80 diesel engine with 3 cylinders and a liquid-cooling system. With an engine displacement of 81 cubic inches and a power output of 18.7 horsepower, it operates at a rated RPM of 2500. This model features a 9-speed partial power shift transmission that includes 9 forward and 3 reverse gears, facilitating a range of speeds suitable for different tasks. The tractor's physical dimensions provide a length of 109.8 inches, a width of 46.5 inches, and a height of 57.7 inches. With a 2WD operating weight of 1786 pounds, it is capable of performing a variety of jobs without the added weight and complexity of a 4WD system. The tractor's overall design and capabilities indicate that it is likely well-suited for light to medium-duty work, including but not limited to garden tilling, mowing, and light soil preparation.
Show more...

Key Specifications

Category: Utility

Power Output: 18.7

Transmission: Partial power shift

Drive Type: 2WD

Operating Weight: 1786

Fuel Type: Diesel

Yanmar FX195 vs. Similar Tractors

Power Output
Poor
Greater than 7% of similar tractors.
Operating Weight
Below Average
Greater than 14% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
3TNB80
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
81
Bore (in)
3.15
Stroke (in)
3.46
Rated RPM
2500
Power Output (hp)
18.7

Transmission

Type
Partial power shift
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
109.8
Width (in)
46.5
Height (in)
57.7
Operating Weight (lb)
1786

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
