Yanmar FV-310

Last Updated: June 2024

Overview

The Yanmar FV-310 is a compact utility tractor that was manufactured by Yanmar between 1991 and 1998. It features a 4x4 MFWD 4WD chassis, underscoring its capability to handle various tasks on different terrains. Powering the FV-310 is a 1.5L Yanmar diesel engine with 3 cylinders, ensuring reliable performance alongside efficient fuel use. It produces 30.1 horsepower, utilizing a liquid-cooled system to maintain engine temperature. The engine features a bore and stroke of 3.39 inches and 3.54 inches respectively and operates at a rated RPM of 2750. An electric starter system facilitates easy activation of the engine. While this tractor comes with a solid foundation of capabilities off the factory line, specific details about its additional features, transmission system, tire sizes, weights, and dimensions were not available. The FV-310 is suited for owners seeking a durable tractor for everyday utility tasks, offering dependable power and the convenience of a four-wheel drive.
Show more...

Key Specifications

Category: Utility

Power Output: 30.1

Drive Type: 4WD

Fuel Type: Diesel

Yanmar FV-310 vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
91.5
Bore (in)
3.39
Stroke (in)
3.54
Rated RPM
2750
Power Output (hp)
30.1

Transmission

Type
-
Forward Gears
-
Reverse Gears
-
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
1998
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
