Yanmar FV-200

Last Updated: June 2024

Overview

The Yanmar FV-200 is a compact utility tractor that was manufactured between 1992 and 1998. It's a versatile and small tractor designed for a variety of tasks in a farm or garden setting. This 4-wheel drive machine, with a 4x4 MFWD chassis configuration, was part of the FV Series known for their reliability and efficiency in small scale operations. Under its hood, the FV-200 packs a 19.2 hp Yanmar diesel engine, with a displacement of 81.2 cubic inches and a bore/stroke of 3.23x3.31 inches. The liquid-cooled, 3-cylinder engine also operates at a rated RPM of 2600. The tractor comes with a manual transmission featuring 12 forward and 4 reverse gears, equipping the user with a wide range of speed options for various tasks. While other specifications such as operator station type, hitch systems, and tire dimensions were not provided, we can infer that, consistent with compact utility tractors, this model aimed to serve operators seeking a small yet powerful assistant for their agricultural or horticultural endeavors.
Show more...

Key Specifications

Category: Utility

Power Output: 19.2

Transmission: Manual

Drive Type: 4WD

Fuel Type: Diesel

Yanmar FV-200 vs. Similar Tractors

Power Output
Poor
Greater than 8% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
81.2
Bore (in)
3.23
Stroke (in)
3.31
Rated RPM
2600
Power Output (hp)
19.2

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
4
Total Gears
16

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
1998
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
