Yanmar F320

Last Updated: June 2024

Overview

The Yanmar F320 is a utility tractor known for its dependability and power. This model is equipped with a Yanmar diesel engine, which delivers 32 horsepower from its 3-cylinder configuration. Notably, the engine has a displacement of 91.3 cubic inches with bore and stroke measurements of 3.31 inches and 3.54 inches respectively. The tractor’s synchromesh transmission offers a total of 12 gears—9 forward and 3 reverse—which helps in meeting diverse operational needs. The machine stands with dimensions of 128.9 inches in length, 57.3 inches in width, and 91.9 inches in height, with a wheelbase of 67.5 inches contributing to its stability. It has a substantial operating weight of 2977 pounds and a rear tire size of 12.4-24. As the lack of available specifications on certain features such as the cooling system type, valve configuration, and exact tire dimensions suggests, owners will have to refer to the original manufacturer's details or contact specialist dealers for complete information. This information suggests a strong tractability and capability, particularly suitable for a variety of utility tasks in different working environments.
Show more...

Key Specifications

Category: Utility

Power Output: 32

Transmission: Synchromesh

Operating Weight: 2977

Fuel Type: Diesel

Yanmar F320 vs. Similar Tractors

Power Output
Below Average
Greater than 27% of similar tractors.
Operating Weight
Below Average
Greater than 25% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
-
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
91.3
Bore (in)
3.31
Stroke (in)
3.54
Rated RPM
-
Power Output (hp)
32

Transmission

Type
Synchromesh
Forward Gears
9
Reverse Gears
3
Total Gears
12

Dimensions

Length (in)
128.9
Width (in)
57.3
Height (in)
91.9
Operating Weight (lb)
2977

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
24
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Rear Type I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
