Yanmar F265

Last Updated: June 2024

Overview

The Yanmar F265 is a compact utility tractor that provides efficient power and reliability for a variety of tasks. Equipped with a 25.6 horsepower Yanmar 3TNB84 diesel engine, it offers 18 forward and 6 reverse gears through a combination of gear and creeper transmissions. With a liquid-cooled engine and a rated RPM of 2500, this tractor provides consistent performance for agricultural applications. The F265 features a two-wheel-drive chassis and supports standard agriculture tires, with the front tires measuring 5.00-15 and the rear tires 12.4-24. It has a wheelbase of 59.5 inches for the 2WD version, providing stability and maneuverability. The tractor's physical dimensions are 112.8 inches in length, 55.5 inches in width, and 59.8 inches in height, with an operating weight between 2249 pounds for the 2WD model and 2414 pounds for the 4WD variant. The Yanmar F265's construction is aimed at offering a balance between size and capability, making it suitable for various farming tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 25.6

Transmission: Gear / Creeper

Drive Type: 2WD

Operating Weight: 2249 (2WD) / 2414 (4WD)

Fuel Type: Diesel

Yanmar F265 vs. Similar Tractors

Power Output
Below Average
Greater than 19% of similar tractors.
Operating Weight
Excellent
Greater than 95% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
3TNB84
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
89.3
Bore (in)
3.31
Stroke (in)
3.46
Rated RPM
2500
Power Output (hp)
25.6

Transmission

Type
Gear / Creeper
Forward Gears
18
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
112.8
Width (in)
55.5
Height (in)
59.8
Operating Weight (lb)
2249 (2WD) / 2414 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agriculture
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
