Yanmar AF865

Last Updated: June 2024

Overview

The Yanmar AF865 is a utility tractor that was manufactured between 2001 and 2005. It features a Yanmar 4TNV102 diesel engine with a displacement of 249.3 cubic inches and a rated power output of 65 horsepower at 2400 RPM. The tractor is equipped with a 4-wheel drive chassis, power steering, and an 18-speed power shuttle transmission. The liquid-cooled engine and direct injection system provide efficient power and reliability in various agricultural applications. The tractor supports a three-point hitch system with a category II/I hitch and operates on standard agricultural tires with a hydraulic wet disk clutch. Measuring 158.3 inches in length, 71.3 inches in width, and 104.7 inches in height, with an operating weight of 7088 lbs, the Yanmar AF865 is built to handle a wide range of tasks on the farm.

Key Specifications

Category: Utility

Power Output: 65

Transmission: Power Shuttle

Drive Type: 4WD

Operating Weight: 7088

Fuel Type: Diesel

Image Gallery

Yanmar AF865 Tractor

Yanmar AF865 vs. Similar Tractors

Power Output

Average

Greater than 61% of similar tractors.

Operating Weight

Average

Greater than 53% of similar tractors.

Technical Specifications

Engine

Manufacturer: Yanmar
Model: 4TNV102
Cooling Type: Liquid-Cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Direct Injection
Cylinders: 4
Displacement (ci): 249.3
Bore (in): -
Stroke (in): -
Rated RPM: 2400
Power Output (hp): 65

Transmission

Type: Power Shuttle
Forward Gears: 18
Reverse Gears: 18
Total Gears: -

Dimensions

Length (in): 158.3
Width (in): 71.3
Height (in): 104.7
Operating Weight (lb): 7088

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural
Manufacture - End Year: 2005
Hitch Type: Three-Point Hitch
Hitch Category: II/I
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
