Yanmar AF655

Last Updated: June 2024

Overview

The Yanmar AF655 is a tractor that was manufactured by Yanmar from 2001 to 2005. It features a 4x4 MFWD 4WD chassis and is powered by a 55 hp Yanmar 4TNV98 four-cylinder diesel engine. This model has a liquid cooling system and operates at a rated RPM of 2500. With a power shuttle transmission, it provides 18 forward and reverse gears. A notable characteristic is its hydraulic wet disc clutch which enhances the transmission's functionality. The tractor's overall length is 138.6 inches, width is 64.6 inches, and height is 97.8 inches, with an operating weight of 4971 pounds. Featuring power steering and electric starting, this machine is designed with usability in mind. It rides on standard agricultural tires, with front tires at a width of 8.3 inches and rear tires at a width of 12.4 inches.
Show more...

Key Specifications

Power Output: 55

Transmission: Power shuttle

Drive Type: 4WD

Operating Weight: 4971

Fuel Type: Diesel

Image Gallery

Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor Yanmar AF655 Tractor

Technical Specifications

Engine

Manufacturer
Yanmar
Model
4TNV98
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural
Cylinders
4
Displacement (ci)
202.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2500
Power Output (hp)
55

Transmission

Type
Power shuttle
Forward Gears
18
Reverse Gears
18
Total Gears
36

Dimensions

Length (in)
138.6
Width (in)
64.6
Height (in)
97.8
Operating Weight (lb)
4971

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
8.3
Rear Tire Diameter (in)
-
Rear Tire Width (in)
12.4
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
2005
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
