Yanmar AF-150

Last Updated: June 2024

Overview

The Yanmar AF-150 is a compact utility tractor that was manufactured by Yanmar from 1997 to 2000. This model features a four-wheel-drive chassis (4x4 MFWD) and is equipped with a liquid-cooled Yanmar 3TNE72 diesel engine that provides 14.8 horsepower at a rated RPM of 2500. The tractor comes with a shuttle transmission type that offers 8 forward and reverse gears, allowing for versatile movement and operation in a variety of tasks. It has a wheelbase of 53.2 inches, which contributes to its stability. The dimensions of the tractor are 103.2 inches in length, 43.3 inches in width, and 73.6 inches in height, giving it a compact build suitable for utility work in confined spaces. The operating weight of the Yanmar AF-150 is 1587 pounds, which provides enough mass for good traction and stability while doing light to medium-duty work. Ground clearance of 11.4 inches allows it to work effectively in uneven terrain without much risk of underbelly damage. Standard agricultural tires outfit the tractor, with the front tires being 5.00-12 and the rear size unspecified but likely to be 8-18 considering standard sizing practices. Additional details, such as the PTO type and speed, the hitch category and lift capacity, hydraulic system type, and braking mechanism, were not specified and remain unknown. This tractor can fulfill various tasks on small farms or estates due to its size and power. Despite its compact size, the AF-150 offers capabilities that make it a good candidate for farming, landscaping, and other utility jobs where a larger tractor would not be feasible. However, considering its limited production years, parts and service may require additional consideration.
Show more...

Key Specifications

Category: Utility

Power Output: 14.8

Transmission: Shuttle

Drive Type: 4WD

Operating Weight: 1587

Fuel Type: Diesel

Yanmar AF-150 vs. Similar Tractors

Power Output
Poor
Greater than 2% of similar tractors.
Operating Weight
Below Average
Greater than 12% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
3TNE72
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
59.1
Bore (in)
2.83
Stroke (in)
3.07
Rated RPM
2500
Power Output (hp)
14.8

Transmission

Type
Shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
103.2
Width (in)
43.3
Height (in)
73.6
Operating Weight (lb)
1587

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2000
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
