Yanmar 223

Last Updated: June 2024

Overview

The Yanmar 223 is a compact tractor that is equipped with a Yanmar 3TNM74F diesel engine. This engine holds a displacement of 60.6 cubic inches, generating 21.5 horsepower and operating at a rated 3200 RPM. The tractor utilizes a hydrostatic transmission type that includes infinite forward and reverse gears within a two-range setup. Steering is presumed to be powered, considering the steering flow is mentioned. The tractor has a wheelbase of 57.9 inches and weighs 1537 pounds. The Yanmar 223 maintains ground clearance of 6.4 inches and a front and rear tread of 35.2 inches. It has the versatility of using lawn/turf or industrial-type tires, with the ROPS height reaching 82.3 inches and the ability to fold down to a height of 66.3 inches for easier storage. It features an open center hydraulic system type and an electric starter system.

Key Specifications

Power Output: 21.5

Transmission: Hydrostatic

Operating Weight: 1537

Fuel Type: Diesel

Image Gallery

Yanmar 223 Tractor

Technical Specifications

Engine

Manufacturer: Yanmar
Model: 3TNM74F
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally Aspirated (Assumed since no forced induction is mentioned)
Cylinders: 3
Displacement (ci): 60.6
Bore (in): 2.92
Stroke (in): 3.03
Rated RPM: 3200
Power Output (hp): 21.5

Transmission

Type: Hydrostatic
Forward Gears: Infinite (2-range)
Reverse Gears: Infinite (2-range)
Total Gears: -

Dimensions

Length (in): 102.1
Width (in): 47.3
Height (in): 82.3 (Assumed from tallest value provided, Height (ROPS))
Operating Weight (lb): 1537

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: Power (Assumed from steering flow information)
Coolant Capacity (qts): 3
Front Tire Diameter (in): -
Front Tire Width (in): 8.50 (Assumed from tire size specification "18x8.50-10")
Rear Tire Diameter (in): -
Rear Tire Width (in): 12.0 (Assumed from tire size specification "26x12.0-12")
Front/Rear Rim Diameter (in): 10/12 (Assumed from tire size specification "front 18x8.50-10" and "rear 26x12.0-12")
Tire Type: Options: Lawn/Turf and Industrial
Manufacture - End Year: -
Hitch Type: Category I (Limited)
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric (Assumed since "Engine - Starter: electric" is given)
Brake Type: -
Hydraulic System Type: Open Center
