XTZ XTZ-240K

Last Updated: June 2024

Overview

The XTZ-240K is a robust 4WD tractor designed to deliver high performance and reliability in various agricultural tasks. It features articulated power steering and a manual transmission with 16 forward gears and 8 reverse, providing flexibility and control during operations. The tractor is fitted with two different diesel engine options; the first is a YaMZ 14.9L 8-cylinder engine that delivers a power output of 240 hp, and the second is an MMZ 7.1L 6-cylinder engine that offers 210 hp. Both engines have a large displacement and are naturally aspirated, indicating substantial torque and efficiency for heavy-duty work. The chassis is built to handle tough terrain, supported by large 23.1R26 agricultural tires for optimal traction. With a substantial operating weight of 18450 lbs and significant dimensions (252 inches in length, 96.9 inches in width, and 136.2 inches in height), the XTZ-240K is capable of substantial workload and stability in the field. However, details about its PTO, hydraulic system, hitch capabilities, and operator station type remain unspecified, as well as manufacturing years, indicating that potential owners may need to consult the manufacturer or additional resources for complete information on these features.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 240, 210

Transmission: Manual

Drive Type: 4WD

Operating Weight: 18450

Fuel Type: Diesel

XTZ XTZ-240K vs. Similar Tractors

Power Output
Excellent
Greater than 93% of similar tractors.
Operating Weight
Average
Greater than 69% of similar tractors.

Technical Specifications

Engine

Manufacturer
YaMZ, MMZ
Model
YaMZ 14.9L 8-cyl diesel, MMZ 7.1L 6-cyl diesel
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
8, 6
Displacement (ci)
906.8, 434.5
Bore (in)
5.12, 4.331
Stroke (in)
5.51, 4.921
Rated RPM
-
Power Output (hp)
240, 210

Transmission

Type
Manual
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
252
Width (in)
96.9
Height (in)
136.2
Operating Weight (lb)
18450

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 Articulated 4WD
Drive Type
4WD
Steering Type
Articulated Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
26
Front Tire Width (in)
-
Rear Tire Diameter (in)
26
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural (Ag)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Hitch Position | Unknown
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
