White Field Boss 43

Last Updated: June 2024

Overview

The White Field Boss 43 is equipped with an Isuzu C240 liquid-cooled diesel engine, producing 45 horsepower with a displacement of 144.6 cubic inches. The engine operates at a rated RPM of 2600, with a dry air cleaner and an electric starter operating on 12 volts. This tractor features a partially synchronized triple-sync transmission with 12 forward and 4 reverse gears. The power steering and open center hydraulic system suggest the tractor is designed for versatility and ease of operation. It has a wheelbase of 79.3 inches and weighs between 3748 pounds for the 2WD version and 4087 pounds for the 4WD version. Dimensions include a length of 136.4 inches, a width of 66.9 inches, and an exhaust height of 80.9 inches. Traction is provided by standard agricultural tires or optional turf tires, depending on the intended use. The exact category and chassis of the tractor are not provided, affecting the ability to determine the tractor's primary design type. The tractor has a Category I hitch and a 540 PTO, commonly found in utility tractors used for a variety of tasks on a farm or property.
Show more...

Key Specifications

Power Output: 45

Transmission: Partially synchronized

Operating Weight: 2WD: 3748, 4WD: 4087

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Isuzu
Model
C240
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural
Cylinders
4
Displacement (ci)
144.6
Bore (in)
3.39
Stroke (in)
4.02
Rated RPM
2600
Power Output (hp)
45

Transmission

Type
Partially synchronized
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
136.4
Width (in)
66.9
Height (in)
80.9
Operating Weight (lb)
2WD: 3748, 4WD: 4087

Power Take-Off (PTO)

PTO Type
540
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag: Front: 6.00-16, Rear: 13.6-28 (2WD); Turf: Front: 8-16 (2WD), Rear: 13.6-28
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
