White 6810

Last Updated: July 2024

Overview

The White 6810 is a versatile utility tractor that was manufactured by White, part of AGCO, from 1998 to 2001. Powered by a Cummins B5.9T turbocharged diesel engine, it provides 119.87 horsepower at 1900 RPM. The tractor is capable of both 2WD and 4WD configurations and features a robust four-speed power shift transmission offering 32 forward and reverse gears, catering to various agricultural tasks. It comes standard with power steering, hydraulic wet disc brakes, and a rear three-point hitch with a lift capacity of 9,000 pounds. The White 6810 provides operator comfort through an optional cab with air-conditioning or a two-post ROPS setup. It supports independent PTO with speeds of 540, 540E, 1000, and 1000E RPM, backed by an advanced closed-center hydraulic system with a pump delivery rate of 28.6 GPM (108.3 l/min) and hydraulic power of 38.5 HP (28.7 kW) at 2750 psi (190 bar). The tractor's weight is 12721 lbs when unladen, demonstrating its substantial build and capability to handle demanding work environments. Additional notable features include a maximum torque of 367 lb.-ft. (498 Nm) at 1500 rpm and a torque rise of 38.4% with a torque rise at 1800 rpm of 307 lb-ft (416 Nm).

Key Specifications

Category: Utility

Power Output: 119.87

Transmission: Four-speed power shift

Drive Type: 4WD optional

Operating Weight: 12721

Fuel Type: Diesel

Image Gallery

White 6810 Tractor

White 6810 vs. Similar Tractors

Power Output

Above Average

Greater than 85% of similar tractors.

Hitch Capacity

Above Average

Greater than 84% of similar tractors.

Operating Weight

Average

Greater than 66% of similar tractors.

Technical Specifications

Engine

Manufacturer: Cummins
Model: B5.9T
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 6
Displacement (ci): 359
Bore (in): 4.016
Stroke (in): 4.72
Rated RPM: 1900
Power Output (hp): 119.87

Transmission

Type: Four-speed power shift
Forward Gears: 32
Reverse Gears: 32
Total Gears: -

Dimensions

Length (in): 172.8
Width (in): 87.8
Height (in): 108.7 cab
Operating Weight (lb): 12721

Power Take-Off (PTO)

PTO Type: Independent with wet disc clutch
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 540E
PTO Speed 3 (rpm): 1000

Miscellaneous

Chassis: -
Drive Type: 4WD optional
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: 2001
Hitch Type: Three-Point Hitch
Hitch Category: II
Hitch Position: Rear
Hitch Capacity (lb): 9000
Operator Station Type: ROPS or Cab with optional air-conditioning
Starter Type: Electric
Brake Type: Hydraulic wet disc
Hydraulic System Type: Closed center

Test Results

Nebraska Tractor Test Laboratory - Test Date: June 14 to 19, 2000

Maximum Power and Fuel Consumption

Maximum Power: 119.87 HP (89.38 kW) at 1900 rpm
Fuel Consumption at Maximum Power: 6.88 Gal/hr (26.08 l/h) with a fuel efficiency of 0.405 lb/hp.hr (0.247 kg/kW.h)
Standard Power Take-off Speed (1000 rpm): 117.83 HP (87.87 kW) with a fuel efficiency of 17.03 Hp.hr/gal (3.35 kW.h/l)
Rated Engine Speed (PTO speed at 1100 rpm): 112.12 HP (82.86 kW)

Drawbar Performance

Maximum Power in 17th (4HB) Gear: 98.50 HP (73.45 kW) with a drawbar pull of 7104 lbs (31.60 kN) and a speed of 5.20 mph (8.37 km/h)
75% of Pull at Maximum Power in 17th Gear: 72.52 HP (54.06 kW) with a drawbar pull of 4885 lbs (21.73 kN) and a speed of 5.87 mph (9.45 km/h)
50% of Pull at Maximum Power in 20th Gear: 52.40 HP (39.07 kW) with a drawbar pull of 3255 lbs (14.48 kN) and a speed of 6.04 mph (9.72 km/h)

Torque and Engine Performance

Maximum Torque: 367 lb.-ft. (498 Nm) at 1500 rpm
Torque Rise: 38.4% with a torque rise at 1800 rpm of 307 lb-ft (416 Nm)

Hydraulic Performance

Maximum Force Exerted: 9194 lbs (40.9 kN) at hitch points
Pump Delivery Rate: 28.6 GPM (108.3 l/min) at minimum pressure and rated engine speed
Hydraulic Power: 38.5 HP (28.7 kW) at delivery pressure of 2750 psi (190 bar)

Overall Efficiency

Fuel Efficiency at Standard PTO Speed (1000 rpm): 17.03 Hp.hr/gal (3.35 kW.h/l)

Nebraska Tractor Test Lab. (2000). Test 1780: White 6810 also AGCO 8785 (Cummins Engine). Lincoln, NE: Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/3470
