White 60

Last Updated: June 2024

Overview

The White 60 is a utility tractor that was produced by White in the United States between 1989 and 1991. It's powered by a Cummins engine with a displacement of 239 cubic inches, 4 cylinders, liquid cooling, and a natural aspiration. The engine outputs 60 hp at 2200 RPM. Available with either a sliding gear or a partial power shift transmission, with 6 forward and 2 reverse or 18 forward and 6 reverse gears respectively. The tractor's chassis is set up in a 2WD configuration, with the option for a 4WD model. It features power steering, dry disc brakes, two-post ROPS, and a substantial fuel tank capacity of 20 US gallons. The White 60 was well-regarded for its durability and versatility in various agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 60

Operating Weight: 8340

Fuel Type: Diesel

Lift Capacity: 4500

White 60 vs. Similar Tractors

Power Output
Average
Greater than 58% of similar tractors.
Hitch Capacity
Above Average
Greater than 73% of similar tractors.
Operating Weight
Average
Greater than 58% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
239
Bore (in)
4.02
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
60

Transmission

Type
-
Forward Gears
18
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
151.5
Width (in)
81.5
Height (in)
96.75
Operating Weight (lb)
8340

Power Take-Off (PTO)

PTO Type
Independent with hydraulic clutch
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
1000
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
24
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
1991
Hitch Type
I/II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
4500
Operator Station Type
Two-post ROPS
Starter Type
Electric
Brake Type
Dry disc
Hydraulic System Type
Open center
