Wheel Horse 416-8

Last Updated: June 2024

Overview

The Wheel Horse 416-8, a 2WD garden tractor part of the 400 series, was manufactured between 1985 and 1992 in South Bend, Indiana, USA by Wheel Horse, under the umbrella of Toro. This model features one of three possible engines – the Kohler K341S or M16S, or the Onan P216 – all of which boast an output of 16 HP at 3600 RPM. This tractor offers a manual steering system and a belt-driven gear transmission comprising 6 forward gears and 2 reverse gears. Noted for its versatility, the 416-8 operates with a fuel capacity of 8.5 liters and provides an open operator station for ease of access and operation. While exact tire dimensions and additional specifications remain unknown, the 416-8 is designed to accommodate various attachments, enhancing its utility in a garden context.

Key Specifications

Category: Lawn and Garden

Power Output: 16

Transmission: Belt-driven gear

Drive Type: 2WD

Operating Weight: 657

Fuel Type: Gasoline

Image Gallery

Wheel Horse 416-8 Tractor

Wheel Horse 416-8 vs. Similar Tractors

Power Output

Average

Greater than 40% of similar tractors.

Operating Weight

Average

Greater than 61% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kohler / Onan
Model: K341S / M16S / P216
Cooling Type: Air-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Gasoline
Induction Type: Naturally aspirated
Cylinders: 2-Jan
Displacement (ci): 35.9
Bore (in): 3.74
Stroke (in): 3.27 / 2.64
Rated RPM: 3600
Power Output (hp): 16

Transmission

Type: Belt-driven gear
Forward Gears: 6
Reverse Gears: 2
Total Gears: 8

Dimensions

Length (in): 65
Width (in): 37
Height (in): 42.1
Operating Weight (lb): 657

Power Take-Off (PTO)

PTO Type: Independent with mechanical clutch
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Manual
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Lawn/turf
Manufacture - End Year: 1992
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: Open
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
