Versatile D100

Last Updated: June 2024

Overview

The Versatile D100 is a 4WD tractor, designed with a focus on ruggedness and reliability. Its chassis features an articulated 4x4 wheel drive configuration, providing enhanced mobility and traction over rough and varied terrain. The tractor leverages an articulated power steering system which, combined with its robust 4WD, allows for improved handling and maneuverability. At the heart of the D100 is a durable Ford diesel engine, with a displacement of 363 cubic inches and a power output of 100 horsepower. This liquid-cooled, inline 6-cylinder engine is tuned to deliver consistent performance for demanding agricultural tasks. The tractor employs a 12-speed gear transmission that offers 12 forward gears and 4 reverse gears, adapting to a variety of working conditions. With a dual set of 16.9-30 ag tires at both the front and the rear, the D100 provides a stable foundation for a wide range of farming operations. While detailed information about the tractor's dimensions, weight, and additional functionalities is not available, its design indicates a solid utility vehicle capable of meeting the needs of rigorous farm work.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 100

Transmission: gear

Drive Type: 4WD

Fuel Type: diesel

Versatile D100 vs. Similar Tractors

Power Output
Above Average
Greater than 82% of similar tractors.

Technical Specifications

Engine

Manufacturer
Ford
Model
-
Cooling Type
liquid-cooled
Cylinder Orientation
inline
Valve Configuration
-
Fuel Type
diesel
Induction Type
-
Cylinders
6
Displacement (ci)
363
Bore (in)
4.12
Stroke (in)
4.524
Rated RPM
-
Power Output (hp)
100

Transmission

Type
gear
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
articulated power
Coolant Capacity (qts)
6
Front Tire Diameter (in)
30
Front Tire Width (in)
16.9
Rear Tire Diameter (in)
30
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
