Versatile 955

Last Updated: June 2024

Overview

The Versatile 955 is a robust and powerful four-wheel-drive tractor designed to meet the needs of farmers and growers requiring heavy-duty performance. Equipped with a Cummins NTA-855-A350, 6-cylinder, aftercooled turbocharged diesel engine, it delivers a substantial 350 horsepower. The liquid-cooled engine contributes to efficient thermal management, ensuring reliability and longevity. The 855 cubic inches of displacement denote a strong, low-end torque characteristic of such large engines. Its articulated power steering helps manoeuvre this sizable machine with precision even in tight spaces. For transmission, it employs a powershift system with 12 forward gears and 2 reverse gears, allowing for a wide range of speed selections to match the workload. The tractor rides on large 24.5x32 front and rear agricultural tires, ensuring optimal traction and stability on varied terrain. The Versatile 955 features an open center hydraulic system and is characterized by a weight of 24,500 lbs, capable of being ballasted to a maximum of 36,000 lbs to suit various operational demands.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 350

Transmission: Power shift

Drive Type: 4WD

Operating Weight: 24500

Fuel Type: Diesel

Versatile 955 vs. Similar Tractors

Power Output
Excellent
Greater than 95% of similar tractors.
Operating Weight
Above Average
Greater than 71% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
NTA-855-A350
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Aftercooled turbocharged
Cylinders
6
Displacement (ci)
855
Bore (in)
5.5
Stroke (in)
6
Rated RPM
2100
Power Output (hp)
350

Transmission

Type
Power shift
Forward Gears
12
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
253
Width (in)
152
Height (in)
126.75
Operating Weight (lb)
24500

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 4WD
Drive Type
4WD
Steering Type
Articulated Power
Coolant Capacity (qts)
61
Front Tire Diameter (in)
32
Front Tire Width (in)
24.5
Rear Tire Diameter (in)
32
Rear Tire Width (in)
24.5
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Rear Type: 4N/3
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
-
Brake Type
-
Hydraulic System Type
Open Center
